PALADIN Cube

SKU:
PAL258
Availability:
Ships from manufacturer. Typically ships within 1-2 days
$636.00
$795.00
(You save $159.00 )

The PALADIN Cube™ is a compact and powerful outdoor floodlight for a wide variety of applications. Using 9x15W RGBW cells it provides a total output of up to 3,200 lumens. Certified to IP65 it features a rugged design with a solid build quality, eliminating the need to worry about dust and water ingress. IP rated connections make it an ideal product to illuminate large areas of any outdoor event with vibrant and powerful colors. It can be operated standing on the floor or be hung in any orientation using the provided omega brackets. Available cell control and strobe features make the PALADIN Cube also a versatile effects fixture or audience blinder.



Specifications

SOURCE

9x 15W RGBW LED Emitters

50,000 Hour Average LED Life*

*Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.



PHOTOMETRIC DATA

6,000K Color Temperature

3,200 Total Lumen Output

14° Beam 25° Field Angle (without diffuser)

26° Beam 52° Field Angle (with diffuser)



CONTROL / CONNECTIONS

11 DMX Channel Modes (32 Total Channels)

3x1 Cell Control

DMX, RDM Protocol Support

Standalone and Master / Slave Operation

4 Button OLED Control Display

IP65 5pin DMX In/Out

IP65 Power In/Out

With Wired Digital Communication Network



SIZE / WEIGHT

Length: 7.8” (199.11mm)

Depth: 5.4” (139mm)

Height: 7.8” (248.04mm)

Weight 10.5 lbs. (4.75kg)



ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz

120W Max Power Consumption

5°F to 113°F (-15°C to 45°C)



APPROVALS / RATINGS

CE | cETLus (pending) | IP65

Manufacturers Warranty
