impression X4 XL

SKU:
7650
Availability:
Ships from manufacturer. Typically ships within 1-2 days
$8,999.25
$11,999.00
(You save $2,999.75 )

The GLP impression X4 XL uses an incredible array of 55 RGBW high output LED’s, rated at 15 watts each. And features a highly efficient zoom range from a tight 7° to a wide 50°. The X4 XL produces a massive amount of light that will throw for extremely long distances.



The impression X4 XL can also be equipped with variable white or RGBY LEDs. Making the impression X4 range one of the most versatile ranges on the market, offering the perfect solutions for any production.

The optical system, originally designed for the GLP impression X4, gives a sharply defined beam. Complete with hard edge in the lower zoom range whilst remaining absolutely homogeneous and soft edged at wider angles. This is all contained within the stylish baseless design that has become synonymous with the GLP impression series. The output is a full RGBW color system, with additional variable color temperature correction control for added flexibility when working with whites. Also featured are an electronic strobe with variable speed, smooth full range dimming – with no color shift – and 16 bit pan and tilt movement, with feedback control.

The impression X4 XL features individually controllable LED’s, allowing a range of different patterns to be created and displayed on the front lenses, including arrows, numbers, letters and much more, either from stock patterns or through user created patterns.



Available Light Source

  • 55 Osram high powered RGBW LEDs
  • Average service life: 50,000 hours

Optical System

  • Motorized zoom system with 7° to 50° beam angle

Movement

  • 8 or 16 Bit resolution selectable
  • Position feedback
  • Range: 660° pan, 260° tilt
  • High precision 3 phase stepping motor control

Shutter / Dimmer

  • Continuous dimmer 0-100%
  • Variable strobe from 1-10 Hz.
  • Random strobe effect
  • Pulse effects

Control

  • DMX-512 protocol
  • Back lit graphic LCD menu
  • Very quiet, temperature controlled ventilation
  • Over temperature protection
  • Color calibration feature
  • Internal color presets
  • Internal macro effects

Power Supply

  • Power consumption: 1100 VA (Watt)
  • Power input: auto sensing 100-240 V AC, 50-60Hz

Connectors

  • DMX: XLR 5 pin and 3 pin
  • Mains voltage: Neutrik Powercon

Operating Conditions

  • Maximum ambient temperature: 113°F  (45°C)

Mounting Options

  • Upright: floor stand (supplied with brackets for ratchet strap.)
  • M10 sockets for direct attachment of half couplers or other clamps
  • Optional omega bracket attachment
  • 2 attachment points for safety wire

Shipping

  • Cardboard box

Housing Colors

  • Standard colors are black, silver & white
  • For other colors please contact sales department

Dimensions

  • (L x W x H): head vertical
    • 7.8″ x 21.6″ x 20.2″  (20 cm x 55 cm x 51.5 cm)

Net Weight

  • 52.9 lbs  (24 kg)
